PD-GA2402CN-0
PD3.2 240W GaN Charger
The 240W GaN charger with PD 3.2 is perfectly compatible with NVIDIA GB10 platform.
It delivers stable high power for AI devices, servers, industrial PCs and smart equipment.
Professionally tested by Chargerlab for reliable performance.
Product Features
  • Supports PD3.2 fast charging protocol, up to 240W high power output
  • Adopts GaN technology, high efficiency and low heat generation
  • Specially optimized for NVIDIA GB10 computing platform
  • AHB topology & fully digital design, realizing primary soft switching and low power loss
  • Complies with Level 7 energy efficiency standard, energy-saving and high-efficiency
Product Parameters
Input 100-120V~3.1A，200-240V~1.56A 50/60Hz
Output

USB-C：

PD 5V⎓3A；9V⎓3A；15V⎓3A；20V⎓5A；28V⎓5A；36V⎓5A；48V⎓5A

AVS：9-20V⎓3A,5A

AVS：15-48V⎓5A 240.0W
Surge Differential mode: ±2KV，Common mode: ±1KV
ESD Contact discharge: ±8KV，Air discharge: ±12KV
Energy Level 7
Dimensions 35(H) × 99 (L) × 99 (W) mm
Core Protocol PD3.2
